Yellow LED On-Off Toggle Switch SPST

SPST toggle switch with an LED tip which illuminates when the switch is in the 'On' position. The switch is suitable for panel mounting and is commonly used for automotive applications.

On-Off operation

SPST contacts

6.3mm quick connect terminals

LED requires 12VDC illumination

Panel cut-out diameter: 12mm

Dimensions: 51.4 x 16 x 28mm (Height x Width x Length)

Maximum Panel Thickness: 5mm
