IPR3FAD1L0S APEM Red LED Round Momentary NO Prewired Push Button Switch SPST IP67

The IPR3FAD1L0S is an illuminated blue button momentary round push button switch with a 12mm bushing and compact package sealed to IP67. The switch features 500mm flying leads and SPST contacts, suitable for applications in harsh environments including automotive.

• Momentary operation
• Blue button
• Red LED
• LED forward voltage: 2.1V
• LED forward current: 20mA
• SPST-NO contacts
• 12mm bushing
• Sealed to IP67
• Panel cut-out: 13.6mm
• 500mm flying leads
• Gold plated silver contacts
• Rating: 5A 28VDC, 0.2A 48VDC, 0.5A 48VAC
• Panel thickness: 1.5-4mm
• Dimensions: 29.8 x 17.5mm (height x diameter)
