Product Description
Specifications
| Colour / Type | Yellow Diffused |
| Size | 5mm |
| Forward Voltage Minimum | 5V |
| Forward Voltage Maximum | 20V |
| Reverse Voltage | 5V |
| Forward Current | Min 8.5mA Max 11.5mA |
| DC Reverse Current | 10uA |
| Pulse forward current | |
| Power dissipation | 120 mW |
| Brightness | 20mcd |
| Viewing Angle | 30° |
| Wavelength | 588nm |
| Working Temperature | -40°C to +70°C |
